Projeto Artístico 2026
Uma performance robótica que utiliza a estética gótica para pautar a crítica social ao Feminicídio. Robótica educacional a serviço da consciência.
Ler Roteiro
O projeto utiliza o arquétipo da Noiva Cadáver para ilustrar o ciclo de violência e o "pra sempre" interrompido pela brutalidade.
Reconhecimento de imagens: Eles executam diferentes ações em resposta a sinais com as mãos ou movimentos corporais.
Evitando colisões: Os robôs evitam colisões uns com os outros enquanto se movem.
Orientação no espaço: Utilizando sensores como giroscópio e motores, o robô identifica sua posição e se movimenta de forma precisa no ambiente.
Interpretação do ambiente: O robô reconhece imagens e sons ao seu redor, permitindo interação e tomada de decisões com base nesses dados.
FONTE COM BALAÚSTRES. FUNDO DE PONTE EM NOITE ESCURA COM ÁRVORES SEM FOLHAS, LUA CHEIA E CÉU AZUL ESCURO. FOCO DA LUZ NO VILÃO.
O Vilão entra produzindo um ar maléfico e manipulador, fino, roupas sociais de época, ar galanteador, fala enquanto ri maléficamente.
LUZES EM JÚLIA E NO VILÃO. Entra Júlia de roupas brancas em alusão a uma noiva, com um saco de dinheiro e uma mala de roupas.
UMA MESA RÚSTICA, MÚSICA AMBIENTE E LEVEMENTE MEDONHA. Eles vão até a mesa. O VILÃO serve a bebida.
Júlia bebe. A música falha/distorce. Ela enfraquece e cai lentamente. O VILÃO pega o dinheiro e o arrasta para fora com desprezo.
LUZ AZUL FRIA. CARLOS entra murmurando e encontra o véu de Júlia.
CARLOS encontra junto ao véu uma taça e um galho e a pega.
A Noiva Cadáver e Carlos se aproximam iniciando uma valsa curta e lenta.
Carlos põe veneno na taça e leva à boca.
MÚSICA TENSA. O VILÃO volta ao palco, assustado.
A Noiva Cadáver para a dança e avança sozinha contra o VILÃO.
O Vilão toma a taça de Carlos e bebe em deboche. Começa a passar mal e morrer.
BLACKOUT enquanto no vídeo de fundo aparecem fotos e reportagens de feminicídios. FIM.
Resumo: Período focado na organização da equipe IFBOTICS, reciclagem de componentes de robôs antigos e definição do roteiro "Noiva Cadáver" como crítica ao Feminicídio.
• 26/02-10/03: Limpeza e inventário.
• 11/03-30/03: Roteiro e trilha sonora.
• 31/03-09/04: Orçamento de figurino e cenário.
Resumo: Fase de materialização visual e construção física. O foco é unir o design do robô, a estrutura de engenharia e a criação do conteúdo audiovisual de fundo para a performance.
• 11/04-30/04: Confecção de figurino e adereços.
• 01/05-15/05: Criação e edição do vídeo de fundo (projeção de impacto social e cenários do roteiro).
• 04/05-08/05: Cálculo de base, centro de massa e corte do acrílico na CNC Laser.
• 2ª Semana de Maio: Montagem estrutural da base e fixação do hardware.
Resumo: Período crítico de engenharia. Instalação de toda a inteligência do robô, fiação, sensores e calibração de movimentos para a performance.
• 16/05 – 30/05 (Eletrônica Base): Instalação da placa de controle (Arduino/ESP32), drivers de motor, organização de cabos e sistema de alimentação (baterias).
• 01/06 – 15/06 (Sensores e Visão): Montagem dos sensores ultrassônicos, infravermelho, giroscópio e câmera para reconhecimento visual.
• 16/06 – 30/06 (Sincronia): Integração dos atuadores para movimentos braços/cabeça sincronizados com o vídeo de fundo e áudios.
• 01/07 – 10/07 (Ensaios): Testes exaustivos de bateria, autonomia e resposta do sistema sob estresse.
• 11/07 – 16/07: Polimento de maquiagem e ajustes finais de cenário.
Resumo: Ajustes finais baseados no feedback da banca e finalização da documentação e vídeos para a apresentação definitiva.
• 18/07-05/08: Implementação de melhorias sugeridas pela comissão.
• 06/08-13/08: Gravação final da performance e conferência de todos os itens de avaliação.
#include "esp_camera.h" // Biblioteca da câmera ESP32-CAM
#include <WiFi.h> // Biblioteca Wi-Fi
#include <WebServer.h> // Servidor web
#define CAMERA_MODEL_AI_THINKER // Define o modelo da câmera
#include "camera_pins.h" // Pinos específicos da câmera
// ================== CONFIG WIFI ==================
const char* ap_ssid = "robot"; // Nome da rede Wi-Fi
const char* ap_password = "12345678"; // Senha da rede
WebServer server(80); // Cria servidor na porta 80
// ================== PÁGINA HTML ==================
void PgVideo() {
String html = "<html><head>";
html += "<meta name='viewport' content='width=device-width, initial-scale=1'>";
html += "<style>";
html += "body{background:#111;color:#fff;text-align:center;font-family:sans-serif;margin:0;padding:0;}"; // Estilo da página
html += "img{width:45%;border-radius:10px;box-shadow:0 0 10px #000;margin-top:15px;}"; // Estilo do vídeo
html += "</style></head><body>";
html += "<h2>Robo Cam - VGA</h2>"; // Título
html += "<img src='/stream'>"; // Imagem puxando o stream
html += "</body></html>";
server.send(200, "text/html", html); // Envia página pro navegador
}
// ================== STREAM DE VÍDEO ==================
void streamTask(void *pvParameters) {
WiFiClient client = *(WiFiClient*)pvParameters; // Cliente conectado
// Cabeçalho HTTP para stream contínuo
String header = "HTTP/1.1 200 OK\r\n";
header += "Content-Type: multipart/x-mixed-replace; boundary=frame\r\n\r\n";
client.print(header); // Envia cabeçalho
while (client.connected()) { // Enquanto cliente estiver conectado
camera_fb_t * fb = esp_camera_fb_get(); // Captura frame da câmera
if (!fb) continue; // Se falhar, tenta de novo
client.print("--frame\r\n"); // Separador de frames
client.print("Content-Type: image/jpeg\r\n\r\n"); // Tipo da imagem
client.write(fb->buf, fb->len); // Envia imagem JPEG
client.print("\r\n");
esp_camera_fb_return(fb); // Libera memória do frame
delay(40); // Controle de FPS (~25 FPS)
}
client.stop(); // Encerra conexão
vTaskDelete(NULL); // Finaliza a task
}
// ================== INICIAR STREAM ==================
void LerVideo() {
WiFiClient client = server.client(); // Pega cliente conectado
// Cria ponteiro do cliente (necessário pra task)
WiFiClient *pclient = new WiFiClient(client);
// Cria task paralela para stream (roda no core 1)
xTaskCreatePinnedToCore(streamTask, "streamTask", 8192, pclient, 1, NULL, 1);
}
// ================== CONFIGURAR CÂMERA ==================
bool iniciarCamera() {
camera_config_t config; // Estrutura de configuração
config.ledc_channel = LEDC_CHANNEL_0;
config.ledc_timer = LEDC_TIMER_0;
// Pinos de dados da câmera
config.pin_d0 = Y2_GPIO_NUM;
config.pin_d1 = Y3_GPIO_NUM;
config.pin_d2 = Y4_GPIO_NUM;
config.pin_d3 = Y5_GPIO_NUM;
config.pin_d4 = Y6_GPIO_NUM;
config.pin_d5 = Y7_GPIO_NUM;
config.pin_d6 = Y8_GPIO_NUM;
config.pin_d7 = Y9_GPIO_NUM;
// Pinos de sincronização
config.pin_xclk = XCLK_GPIO_NUM;
config.pin_pclk = PCLK_GPIO_NUM;
config.pin_vsync = VSYNC_GPIO_NUM;
config.pin_href = HREF_GPIO_NUM;
// Comunicação interna
config.pin_sscb_sda = SIOD_GPIO_NUM;
config.pin_sscb_scl = SIOC_GPIO_NUM;
// Controle de energia/reset
config.pin_pwdn = PWDN_GPIO_NUM;
config.pin_reset = RESET_GPIO_NUM;
config.xclk_freq_hz = 20000000; // Frequência do clock
config.pixel_format = PIXFORMAT_JPEG; // Formato da imagem
// ================== QUALIDADE ==================
config.frame_size = FRAMESIZE_VGA; // 640x480
config.jpeg_quality = 12; // Qualidade (menor = melhor)
config.fb_count = 1; // Buffer
// Inicializa câmera
if (esp_camera_init(&config) != ESP_OK) return false;
// Espelhamento horizontal
sensor_t * s = esp_camera_sensor_get();
s->set_hmirror(s, 1);
return true; // Sucesso
}
// ================== SETUP ==================
void setup() {
Serial.begin(115200); // Inicia comunicação serial
// Inicializa câmera
if (!iniciarCamera()) {
Serial.println("ERRO ao iniciar câmera.");
return;
}
WiFi.mode(WIFI_AP); // Modo Access Point
WiFi.softAP(ap_ssid, ap_password); // Cria rede Wi-Fi
pinMode(FLASH_GPIO_NUM, OUTPUT); // LED flash
digitalWrite(FLASH_GPIO_NUM, LOW); // Desliga flash
// Rotas do servidor
server.on("/", PgVideo); // Página principal
server.on("/stream", LerVideo); // Stream de vídeo
server.begin(); // Inicia servidor
}
// ================== LOOP ==================
void loop() {
server.handleClient(); // Atende requisições
delay(0); // Evita travamento do sistema
}
// ================== PWM ==================
#define PINO_PWM1 5 // Controle de velocidade motor 1
#define PINO_PWM2 6 // Controle de velocidade motor 2
// ================== SHIFT REGISTER + DRIVER ==================
#define PINO_SHCP 2 // Clock de deslocamento (Shift Clock)
#define PINO_EN 7 // Enable (ativa/desativa os motores)
#define PINO_DATA 8 // Entrada de dados seriais
#define PINO_STCP 4 // Latch (trava os dados enviados)
// ================== DIREÇÕES ==================
const int FRENTE = 92; // Anda para frente
const int RE = 163; // Anda para trás
const int ESQUERDA = 149; // Gira para esquerda
const int DIREITA = 106; // Gira para direita
// Movimentos diagonais / ajustes finos
const int CIMA_ESQ = 20;
const int BAIXO_ESQ = 129;
const int CIMA_DIR = 72;
const int BAIXO_DIR = 34;
// Giro no próprio eixo
const int ANTI_HORARIO = 172; // Gira para esquerda (eixo)
const int HORARIO = 83; // Gira para direita (eixo)
const int PARAR = 0; // Para motores
const int VELOCIDADE = 250; // Velocidade máxima (quase 255)
// ================== SETUP ==================
void setup() {
// Configura pinos do registrador
pinMode(PINO_SHCP, OUTPUT);
pinMode(PINO_EN, OUTPUT);
pinMode(PINO_DATA, OUTPUT);
pinMode(PINO_STCP, OUTPUT);
// Configura PWM
pinMode(PINO_PWM1, OUTPUT);
pinMode(PINO_PWM2, OUTPUT);
}
// ================== CONTROLE DOS MOTORES ==================
void LigarMotores(int direcao, int velocidade) {
digitalWrite(PINO_EN, LOW); // Ativa saída do registrador
analogWrite(PINO_PWM1, velocidade); // Velocidade motor 1
analogWrite(PINO_PWM2, velocidade); // Velocidade motor 2
digitalWrite(PINO_STCP, LOW); // Prepara envio de dados
shiftOut(PINO_DATA, PINO_SHCP, MSBFIRST, direcao); // Envia comando
digitalWrite(PINO_STCP, HIGH); // Executa movimento
}
// ================== LOOP ==================
void loop() {
// Anda para frente
LigarMotores(FRENTE, VELOCIDADE);
delay(1000);
// Anda para trás
LigarMotores(RE, VELOCIDADE);
delay(1000);
// Avança um pouco
LigarMotores(FRENTE, VELOCIDADE);
delay(500);
// Gira esquerda
LigarMotores(ESQUERDA, VELOCIDADE);
delay(1000);
// Gira direita
LigarMotores(DIREITA, VELOCIDADE);
delay(1000);
// Movimento diagonal superior esquerda
LigarMotores(CIMA_ESQ, VELOCIDADE);
delay(1000);
// Movimento diagonal inferior direita
LigarMotores(BAIXO_DIR, VELOCIDADE);
delay(1000);
// Movimento diagonal inferior esquerda
LigarMotores(BAIXO_ESQ, VELOCIDADE);
delay(1000);
// Movimento diagonal superior direita
LigarMotores(CIMA_DIR, VELOCIDADE);
delay(1000);
// Giro no próprio eixo (sentido horário)
LigarMotores(HORARIO, VELOCIDADE);
delay(1500);
// Giro no próprio eixo (sentido anti-horário)
LigarMotores(ANTI_HORARIO, VELOCIDADE);
delay(1500);
// Para o robô
LigarMotores(PARAR, VELOCIDADE);
delay(5000);
}
#define PINO_PWM1 5 // PWM motor esquerdo (controle de velocidade)
#define PINO_PWM2 6 // PWM motor direito
#define PINO_SHCP 2 // Clock do registrador 74HC595
#define PINO_EN 7 // Enable do registrador
#define PINO_DATA 8 // Entrada de dados
#define PINO_STCP 4 // Latch (trava os dados enviados)
// ================== SENSORES DE LINHA ==================
#define SENSOR_ESQ A0 // Sensor esquerdo
#define SENSOR_CENTRO A1 // Sensor central
#define SENSOR_DIR A2 // Sensor direito
// ================== DIREÇÕES ==================
const int FRENTE = 92; // Anda para frente
const int RE = 163; // Ré
const int ESQUERDA = 149; // Gira esquerda
const int DIREITA = 106; // Gira direita
// Movimentos mais finos (ajustes)
const int CIMA_ESQ = 72;
const int BAIXO_ESQ = 34;
const int CIMA_DIR = 20;
const int BAIXO_DIR = 129;
const int PARAR = 0; // Para motores
// Rotação no próprio eixo
const int ANTI_HORARIO = 172; // Giro esquerda
const int HORARIO = 83; // Giro direita
// Velocidades
const int VP = 170; // Velocidade padrão
const int VPA = 200; // Velocidade mais alta
// ================== VARIÁVEIS DOS SENSORES ==================
int Esq; // Valor do sensor esquerdo
int Centro; // Valor do sensor central
int Dir; // Valor do sensor direito
// ================== LIMITES ==================
int LIMITE_PRETO = 450; // Valor mínimo para considerar "preto"
int LIMITE_BRANCO = 150; // Valor máximo para considerar "branco"
// ================== CONTROLE DOS MOTORES ==================
void LigarMotores(int direcao, int velocidade) {
digitalWrite(PINO_EN, LOW); // Ativa o registrador
analogWrite(PINO_PWM1, velocidade); // Define velocidade motor esquerdo
analogWrite(PINO_PWM2, velocidade); // Define velocidade motor direito
digitalWrite(PINO_STCP, LOW); // Prepara envio
shiftOut(PINO_DATA, PINO_SHCP, MSBFIRST, direcao); // Envia comando
digitalWrite(PINO_STCP, HIGH); // Executa comando
}
// ================== SETUP ==================
void setup() {
// Configuração dos pinos do registrador
pinMode(PINO_SHCP, OUTPUT);
pinMode(PINO_EN, OUTPUT);
pinMode(PINO_DATA, OUTPUT);
pinMode(PINO_STCP, OUTPUT);
// PWM
pinMode(PINO_PWM1, OUTPUT);
pinMode(PINO_PWM2, OUTPUT);
// Sensores
pinMode(SENSOR_ESQ, INPUT);
pinMode(SENSOR_CENTRO, INPUT);
pinMode(SENSOR_DIR, INPUT);
Serial.begin(115200); // Monitor serial (debug)
}
// ================== LOOP ==================
void loop() {
// Lê os sensores
Esq = analogRead(SENSOR_ESQ);
Centro = analogRead(SENSOR_CENTRO);
Dir = analogRead(SENSOR_DIR);
/*
// Debug (opcional)
Serial.print(Esq);
Serial.print(",");
Serial.print(Centro);
Serial.print(",");
Serial.println(Dir);
*/
// ================== LÓGICA ==================
// Caso 1: tudo branco → segue reto
if (Esq <= LIMITE_BRANCO && Centro <= LIMITE_BRANCO && Dir <= LIMITE_BRANCO) {
LigarMotores(FRENTE, VP);
}
// Caso 2: linha no centro → segue reto
if (Esq <= LIMITE_BRANCO && Centro >= LIMITE_PRETO && Dir <= LIMITE_BRANCO) {
LigarMotores(FRENTE, VP);
}
// Caso 3: linha puxando esquerda → gira esquerda leve
else if (Esq >= LIMITE_PRETO && Centro >= LIMITE_PRETO && Dir <= LIMITE_BRANCO) {
LigarMotores(ANTI_HORARIO, VP);
}
// Caso 4: só esquerda detecta → gira mais forte
else if (Esq >= LIMITE_PRETO && Centro <= LIMITE_BRANCO && Dir <= LIMITE_BRANCO) {
LigarMotores(ANTI_HORARIO, VPA);
}
// Caso 5: só direita detecta → gira forte direita
else if (Esq <= LIMITE_BRANCO && Centro <= LIMITE_BRANCO && Dir >= LIMITE_PRETO) {
LigarMotores(HORARIO, VPA);
}
// Caso 6: direita + centro → ajuste leve direita
else if (Esq <= LIMITE_BRANCO && Centro >= LIMITE_PRETO && Dir >= LIMITE_PRETO) {
LigarMotores(HORARIO, VP);
}
// Caso 7: tudo preto → provavelmente chegou no fim → para
else if (Esq >= LIMITE_PRETO && Centro >= LIMITE_PRETO && Dir >= LIMITE_PRETO) {
LigarMotores(PARAR, 0);
}
}
// ================== SENSOR ULTRASSÔNICO ==================
#define PINO_TRIG 12 // Pino que envia o pulso
#define PINO_ECHO 13 // Pino que recebe o eco
// ================== MOTORES + 74HC595 ==================
#define PINO_PWM1 5 // PWM motor 1
#define PINO_PWM2 6 // PWM motor 2
#define PINO_SHCP 2 // Clock do registrador
#define PINO_EN 7 // Enable
#define PINO_DATA 8 // Dados
#define PINO_STCP 4 // Latch
// ================== SENSORES DE LINHA ==================
#define SENSOR_ESQ A0 // Sensor esquerdo
#define SENSOR_CENTRO A1 // Sensor central
#define SENSOR_DIR A2 // Sensor direito
// ================== DIREÇÕES ==================
const int FRENTE = 92; // Frente
const int RE = 163; // Ré
const int ESQUERDA = 149; // Gira esquerda
const int DIREITA = 106; // Gira direita
const int PARAR = 0; // Para
const int ANTI_HORARIO = 172; // Giro eixo esquerda
const int HORARIO = 83; // Giro eixo direita
// ================== VARIÁVEIS ==================
int Esq, Centro, Dir; // Leituras dos sensores
int LIMITE_PRETO = 450; // Limiar para detectar linha preta
const int VELOCIDADE = 220; // Velocidade padrão
const float DISTANCIA_OBSTACULO = 12.0; // Distância mínima (cm)
// ================== MEDIR DISTÂNCIA ==================
float medirDistancia() {
digitalWrite(PINO_TRIG, LOW); // Garante desligado
delayMicroseconds(2);
digitalWrite(PINO_TRIG, HIGH); // Dispara pulso
delayMicroseconds(10);
digitalWrite(PINO_TRIG, LOW);
float dist = pulseIn(PINO_ECHO, HIGH, 25000) / 58.0; // Converte para cm
if (dist <= 0 || dist > 200) return 999; // Erro → considera longe
return dist;
}
// ================== CONTROLE DOS MOTORES ==================
void LigarMotores(int direcao, int velocidade) {
digitalWrite(PINO_EN, LOW); // Ativa registrador
analogWrite(PINO_PWM1, velocidade); // Velocidade motor 1
analogWrite(PINO_PWM2, velocidade); // Velocidade motor 2
digitalWrite(PINO_STCP, LOW); // Prepara envio
shiftOut(PINO_DATA, PINO_SHCP, MSBFIRST, direcao); // Envia comando
digitalWrite(PINO_STCP, HIGH); // Executa
}
// ================== DESVIO DE OBSTÁCULO ==================
void desviarObstaculo() {
LigarMotores(PARAR, 0); // Para antes de decidir
delay(100);
// Gira para direita
LigarMotores(DIREITA, VELOCIDADE);
delay(1000);
LigarMotores(PARAR, 0);
delay(100);
// Avança para contornar
LigarMotores(FRENTE, VELOCIDADE);
delay(1400);
LigarMotores(PARAR, 0);
delay(100);
// Corrige voltando para esquerda
LigarMotores(ESQUERDA, VELOCIDADE);
delay(1100);
}
// ================== SETUP ==================
void setup() {
// Sensor ultrassônico
pinMode(PINO_TRIG, OUTPUT);
pinMode(PINO_ECHO, INPUT);
// Motores
pinMode(PINO_SHCP, OUTPUT);
pinMode(PINO_EN, OUTPUT);
pinMode(PINO_DATA, OUTPUT);
pinMode(PINO_STCP, OUTPUT);
pinMode(PINO_PWM1, OUTPUT);
pinMode(PINO_PWM2, OUTPUT);
// Sensores de linha
pinMode(SENSOR_ESQ, INPUT);
pinMode(SENSOR_CENTRO, INPUT);
pinMode(SENSOR_DIR, INPUT);
Serial.begin(115200); // Debug
}
// ================== LOOP ==================
void loop() {
// Leitura dos sensores
Esq = analogRead(SENSOR_ESQ);
Centro = analogRead(SENSOR_CENTRO);
Dir = analogRead(SENSOR_DIR);
// Exibe valores no serial
Serial.print(Esq); Serial.print(",");
Serial.print(Centro); Serial.print(",");
Serial.println(Dir);
// ================== LÓGICA ==================
// Linha no centro → segue em frente
if (Esq < LIMITE_PRETO && Centro >= LIMITE_PRETO && Dir < LIMITE_PRETO) {
LigarMotores(FRENTE, VELOCIDADE);
// Verifica obstáculo enquanto anda
float distancia = medirDistancia();
if (distancia <= DISTANCIA_OBSTACULO) {
desviarObstaculo(); // Desvia
return; // Evita executar resto do loop
}
}
// Linha puxando esquerda
else if (Esq >= LIMITE_PRETO && Centro >= LIMITE_PRETO && Dir < LIMITE_PRETO) {
LigarMotores(ANTI_HORARIO, VELOCIDADE);
}
// Só esquerda detecta
else if (Esq >= LIMITE_PRETO && Centro < LIMITE_PRETO && Dir < LIMITE_PRETO) {
LigarMotores(ANTI_HORARIO, VELOCIDADE);
}
// Só direita detecta
else if (Esq < LIMITE_PRETO && Centro < LIMITE_PRETO && Dir >= LIMITE_PRETO) {
LigarMotores(HORARIO, VELOCIDADE);
}
// Direita + centro
else if (Esq < LIMITE_PRETO && Centro >= LIMITE_PRETO && Dir >= LIMITE_PRETO) {
LigarMotores(HORARIO, VELOCIDADE);
}
// Tudo preto → parar
else if (Esq >= LIMITE_PRETO && Centro >= LIMITE_PRETO && Dir >= LIMITE_PRETO) {
LigarMotores(PARAR, 0);
}
}
// Estabilização via hardware
// giroscópio + desvio com sensor ultrassônico
#include <Servo.h>
// ==================== SERVO E SENSOR ====================
Servo servoSensor;
#define PINO_SERVO 9
#define PINO_TRIG 12
#define PINO_ECHO 13
// ==================== CONTROLE DOS MOTORES (74HC595) ====================
#define PINO_SHCP 2
#define PINO_EN 7
#define PINO_DATA 8
#define PINO_STCP 4
// ==================== PWM ====================
#define PINO_PWM1 5
#define PINO_PWM2 6
// ==================== DIREÇÕES ====================
const int FRENTE = 92;
const int RE = 163;
const int ESQUERDA = 149;
const int DIREITA = 106;
const int PARAR_MOTORES = 0;
// ==================== CONFIG ====================
const int VELOCIDADE = 220;
const float DISTANCIA_OBSTACULO = 20.0;
// ==================== MEDIR DISTÂNCIA ====================
float medirDistancia() {
digitalWrite(PINO_TRIG, LOW);
delayMicroseconds(2);
digitalWrite(PINO_TRIG, HIGH);
delayMicroseconds(10);
digitalWrite(PINO_TRIG, LOW);
float dist = pulseIn(PINO_ECHO, HIGH, 25000) / 58.0;
if (dist <= 0 || dist > 200) return 999;
return dist;
}
// ==================== MOTORES ====================
void LigarMotores(int direcao, int velocidade) {
digitalWrite(PINO_EN, LOW);
analogWrite(PINO_PWM1, velocidade);
analogWrite(PINO_PWM2, velocidade);
digitalWrite(PINO_STCP, LOW);
shiftOut(PINO_DATA, PINO_SHCP, MSBFIRST, direcao);
digitalWrite(PINO_STCP, HIGH);
}
// ==================== DESVIO ====================
void desviarObstaculo() {
LigarMotores(PARAR_MOTORES, 0);
delay(100);
LigarMotores(DIREITA, VELOCIDADE);
delay(1000);
LigarMotores(PARAR_MOTORES, 0);
delay(100);
LigarMotores(FRENTE, VELOCIDADE);
delay(1700);
LigarMotores(PARAR_MOTORES, 0);
delay(100);
LigarMotores(ESQUERDA, VELOCIDADE);
delay(1100);
LigarMotores(PARAR_MOTORES, 0);
delay(2000);
}
// ==================== SETUP ====================
void setup() {
Serial.begin(9600);
servoSensor.attach(PINO_SERVO, 700, 2400);
servoSensor.write(90);
pinMode(PINO_TRIG, OUTPUT);
pinMode(PINO_ECHO, INPUT);
pinMode(PINO_SHCP, OUTPUT);
pinMode(PINO_EN, OUTPUT);
pinMode(PINO_DATA, OUTPUT);
pinMode(PINO_STCP, OUTPUT);
pinMode(PINO_PWM1, OUTPUT);
pinMode(PINO_PWM2, OUTPUT);
delay(400);
}
// ==================== LOOP ====================
void loop() {
float distancia = medirDistancia();
if (distancia > DISTANCIA_OBSTACULO) {
LigarMotores(FRENTE, VELOCIDADE);
} else {
desviarObstaculo();
}
delay(80);
}
// Funções auxiliares extras # extra
